Artnet to DMX512 Node Converter Pixel Amplifier Controller
Artnet to DMX512 Node Converter Pixel Amplifier Controller
Artnet to DMX512 Node Converter Pixel Amplifier Controller
Artnet to DMX512 Node Converter Pixel Amplifier Controller
Artnet to DMX512 Node Converter Pixel Amplifier Controller
Artnet to DMX512 Node Converter Pixel Amplifier Controller
Artnet to DMX512 Node Converter Pixel Amplifier Controller
Artnet to DMX512 Node Converter Pixel Amplifier Controller
Artnet to DMX512 Node Converter Pixel Amplifier Controller
Artnet to DMX512 Node Converter Pixel Amplifier Controller
Artnet to DMX512 Node Converter Pixel Amplifier Controller

Artnet to DMX512 Node Converter Pixel Amplifier Controller

Model NO.
CL-YM501
Minimum order quantity:
1 piece
Supply Ability:
1000 piece / Quarterly
Country of Origin:
Shenzhen
Quantity:
  • Place of Origin:CN;GUA
  • Type:Remote Control
  • Voltage:220V
  • Brand Name:Clen
  • Max. Load Power:10W
  • Size:260*154*45mm
  • Output Data Signal:TTL
  • Store Interface:SD card
  • Weight:1085g
  • Color:grey
  • Grey Grade:65536
  • Pixel:4*512
  • Output Control Port:4
  • Warranty:2 Years

Artnet to DMX512 Node Converter Pixel Amplifier Controller


Descriptions

You can use these LED controllers to create unique lighting effects for your LED Light Strips, LED Ribbon, LED Metero Tubes and LED Modules.

Produt NameLED Controller
Input Voltage220V
Max Power10W
Size260*154*45mm
Weight1085g
Output Control Port4 port
Maximum Control Pixels4*512 Pixel
The Output Data SignalTTL
Storage InterfaceSD card
Gray Lecels65536
Supporting SoftwareLED Control Software

Details




On-line control

1. Run"LED studio software",to control below pixels lights(TTL signal output)Single line:TM1804 TM1829 UCS1903 TLS3001 TLS3008 etc. Two lines:DMX512 P9813 LPD6803 LPD8806 SM16716 WS2801 MBI6021 MBI6024 MY9221 etc. Stand alone: 512pixels*4ports TTL signal output. To control more pixels,need to work with slaver controller.

2. Run MADRIX software, to control standard dmx512 pixel lights;Stand alone: 512channel*4ports dmx512 signal output. To control more pixels,need to work with slaver controller.


Features

1. a cascade control port

2. Ethernet connection LED controller

3.One output port can control 512 pixels

4. Control mode: on-line control / off control

5. EMC design, with good anti-jamming capability

6. Playback speed: the maximum speed of not less than 25 frames / sec

Send Inquiry Now

company

ShenzhenClen Optoelectronics Co., Ltd. was established in 2007, it is a high starting point, strength, product development, manufacturing, sales and service as one of the LED professionalmanufacturer. The company is committed to high quality LED lighting and landscape decoration production, technical support and sales services, the main products are LED digital strip, LED pixel module, DMX lamps, LED spot, line source, etc., and cansupport OEM & ODM. As the first company producting digital led strips, we have a strict quality inspection system and passed ISO9001: 2000 quality testing, CE and RoHS certification. Good quality, reasonable price and stable delivery of products allows the company to get a good reputation in the industry. Our products are popular all over the world, exported to Japan, Korea, the Middle East, Europe and other markets.

0723

FAQ

Q1.Why choose Shenzhen Clen Optoelectronics Co.,Ltd?
A: We are a manufacturer in this industry for 10 years, we have advanced equipment, excellent production team and our own designers and engineers, we can provide professional severice and also OEM severice. Welcome to visit the factory to comfirm.

Q2. How to place an order ?
A: Pls provide your requirements or application and send us order by E-mail with your detail information,then we will send you a PI to confirm .then, if all information is right and you can make 30% deposit payment.Finally, we will arrange order as soon as possible once received your payment.

Q3. Does Clen support customer design order?
A: Yes, Clen supports OEM/ODM order.

Q4. What's your payment term ?
A: 30% deposit and full payment before shipment , we can accept payment by Paypal, MoneyGram, L/C, Western Union , T/T and Alibaba Trade Assurance Order

Q5. What is your delivery time ,Can we receive our goods on time?
A: We offer fast lead time ,usally 1-2 days if on stocks , 3--5 days if out of stocks. Please contact us for a accurate delivery date in advance.

Q6. What is Warranty of Clen products?
A: 2 years warranty since goods shipped.
